Three Layer roofing Panel Roll Forming Machines Are On Shipping

Three layer roof roll forming machine also can be called triple layer roll forming machine, our first batch  three sets three layer roof roll forming machines are loading containers for shipping to Philippines today. The machine details is as below:

• With feeding guider and manual pre-shear
•

• Gear/Sprocket driving;
•

• Upper Level for YX28-236-954 profile, 16-station to form
•

• Middle layer for YX22-265-1060 profile, 16-station to form
•

• Lower Level for YX22-143-1001 profile, 17-step to form
•

• Rollers manufactured from 45#, CNC lathes, hard Chrome Coated
•

• Shafts Diameter=ф75mm, Precision Machined, fine Polished
•

• Main motor =15KW*3, Frequency speed control
•

• The three levels can’t be run at the same time
•

• Manual Clutch to switch the driven system
•

• Forming speed: Approx. 25-30m/min

•
